VEGA ULTRA 1300

The Vega Ultra 1300 is an exceptionally heavy-duty 3-axis (optional 4-axis) CNC machining centre with Schmalz vacuum consoles and the unique Schmalz hoseless vacuum piston system.

A gantry-type construction ensures extra stability and precision. Combined with an X-axis machining length of up to 6000mm, for example, and the possibility of pendulum operation, makes this machine a real winner.

With impressive machining accuracy, this machine ensures perfect drilling and milling results time after time.
Simple control via state-of-the-art CNC technology with NC-Hops software as standard.

The perfect machine for companies looking for flexibility. Cabinets, stairs, windows or customisation, the Vega Ultra 1300 does it with ease.

VEGA ULTRA 1300

Back to overview

CNC technology in affordable form, that's what the Vega Ultra 1300 stands for. With its very spacious standard design accessible to everyone, this is a CNC machine for heavy and flexible work.

Coupling CNC technology with top performance, the Vega Ultra 1300 does it with ease even in an industrial environment. This machine can become the heart of your machining operations in your workshop.

The highly intuitive user interface with logical arrangement of control elements ensures flawless integration into your operation.
Control via external CAD/CAM systems can be perfectly integrated. Fitting the machine into automated projects is no problem either.

Reliable, powerful, modern high-tech even for heavy-duty work and yet individually and customisable if required.

Show more

Key highlights at a glance

  • Very robust construction for maximum stability and precision
  • Gantry design
  • X-axis operating lengths 2500 / 3200 / 4500 / 6000 mm
  • Very easy-to-use operating software
  • Extended drill head DH17
  • Automatic centralised lubrication
  • Automatic tool length measuring system
  • Unbeatable value for money

AES machines are characterised by extremely solid construction and use of the latest technologies.
Thanks to the wide range, there is the right machine for every application.

VEGA ULTRA 1300 Technical data

  • Bridge-type machine, Y axis reach 1300mm
  • Workfield: X=2500 / 3200 / 4500 / 6000 mm, Y=1300 mm, Z=300 mm
  • Operating speeds: X= 100m/min, Y = 100m/min, Z = 20m/min.
  • Drill head DH17 / V=X6+Y4, H=X2+2 + Y1+1, S=X
  • 14-fold linear tool change, all positions with anti-crash control sensors
  • 1 work field
  • 2 Machining areas for pendelum working (for models 1332,1345 & 1360)
  • 2 lifters for model 1325, 4 for model 1332 &1345, 6 for model 1360
  • 4 Schmalz consoles, 1 stop behind, 12 vacuum cups (for model 1325)
  • Controlled central extraction connection
  • 6 Schmalz consoles, 1 stop behind, 18 vacuum cups (for model 1332)
  • 8 Schmalz consoles, 1 stop behind, 24 vacuum cups (for model 1345)
  • 10 Schmalz consoles, 1 stop behind, 30 vacuum cups (for model 1360)
  • Automatic tool length measuring system
  • Automatic centralised lubrication
  • All reference stops with control sensors
  • Operator control screen integrated in electrical cabinet
  • CE safety system (to be provided)
  • Vacuum pump 100m³/h (Vega Ultra 1345 + Vega Ultra 1360: 140m³/h)
  • NC Hops CAD/CAM user interface in combination with the Controller for axis control. Easy graphic programming of workpieces. Graphic representation of workpiece, machine details, clamps, ect possible. DXF, STL, STEP
  • Milling motor 9Kw/12Pk HSK-F63 with ceramic bearings and pneumatically height-adjustable extraction hood
  • Visual status indication of the machine
