12″ colour screen
Front swing-out support rail on heavy-duty swing arms extendable up to 1.6M
Automatic lubrication for the conveyor chain
Belt at top and barrier roller at front
Front and rear fitted with spraying media
PVC chip collector at the top of the machine
Motorised run-in guide
2 heavy-duty diamond cutters D100mm
Cartridge delivery system for both cartridges and granules
Motorised pressure zone with 3 large rollers of which 1 motorised
2 motorised chop saws straight or bevelled from the control unit
Gross milling on gantry with motorised height adjustment of upper grossing cutter
2 double milling units for longitudinal milling and rounding of corners
Motorised PVC scraper on gantry
Surface scraper
Polishing brushes

Voltage : 3x380 V
Panel thickness : 6-60 mm
Min. panel dimensions : 60x140 mm
Max. edge material : 0,4-25 mm
Max. height of edge material : 65 mm
Feed speed : 8-20 m/min
Machine length : 8160 mm
