table length 1000 mm
Table width 800 mm
Total length of table 1000 mm
Table height 880 mm
Table opening 230 mm
Milling spindle diameter 30 mm
Tiltable cutter axis -5 / +45 °
Interchangeable spindle X
Usable clamping length of cutter spindle 120 mm
Cutter spindle height adjustment 180 mm
Max. diameter of profiling tool under table 210 mm
Max. diameter of profiling tool above table 335 mm
Speeds 3000-4000-6000-8000-10000 r/min
Diameter extraction nozzles on router guard 120 mm
Diameter extraction nozzles under table 100 mm
Motor 7.5 hp
Dimensions (installed) 1230x1030x1340 mm
Weight 470 kg

Standard equipment
- cast iron, finely planed tables
- hardened, ground and electronically balanced milling spindle guarantees vibration-free operation
- exchangeable, inclinable milling cutter shaft diameter 30 mm
- cast-iron adjustable milling cutter guard with anodised aluminium milling guide with fine adjustment
- anodised aluminium milling cutters with fine adjustment
- LED speed display
- fast belt movement
- simple blocking of the milling cutter axis
- electrically reversible direction of rotation of the milling cutter shaft
- dust extraction on the router guard and under the table surface
